River Schematic / Geometry Screen
Selected element is highlighted here. Later this panel will support GeoJSON and shapefile display.
Upstream Inflow
Reach 1: 12.5 km
Reach 2: 8.0 km
Reach 3: Future
Outlet
Geometry note:
This is now a clean schematic view. Later we will replace or combine it with real river geometry,
GeoJSON, shapefile conversion, lateral inflow points, and measured river length.
Project Properties
Basic information for the modelling project.
